Yealink Bluetooth setup

BT41 Bluetooth USB Dongle

USB Dongle for Bluetooth Headsets

The Bluetooth USB dongle adds Bluetooth connectivity to your IP Phone with a wide variety of Blue- tooth Headsets, allowing you to receive calls wherever you are in the office. Compatible with Bluetooth specification V4.1, back compatible with Bluetooth 1.1, 1.2, 2.0 and 3.0 for wide-ranging use.

> Supports Yealink SIP-T27G/T29G/T46G/T48G/T41S/T42S/T46S/T48S/T53 > Answer/Terminate calls through wireless headset
> 10m Range

Specifications

Main Features

> Bluetooth specification: V4.1
> Enhanced Data Rata (edr) compliant for both 2Mbps and 3Mbps supported
> A2DP technology
> Support 8K NBS (apply to SIP-T27G/T29G/T46G/T48G/T41S/T42S/T46S/T48S) > Support 16K WBS (apply to SIP-T53)
> Operating distance: 10 meters
> Answer incoming calls through Bluetooth headset
> Terminate calls through Bluetooth headset
> Adjusts the volume of Bluetooth headset through Bluetooth headset or your phone > Bluetooth frequency range: 2.402GHz-2.480GHz
> Built-in security
> Low power consumption

Physical Features

• >  Supports Yealink SIP-T27G/T29G/T46G/T48G/T41S/T42S/T46S/T48S/T53 (version 82 or later)
• >  USB2.0 interface
• >  Symbol rate: 3Mbps
• >  Dimensions: 18mm*14mm*5.5mm
• >  Weight: 2g
  Package Features
  > Qty/CTN: 40 PCS
  > N.W/CTN: 1.6 kg
  > G.W/CTN: 2.6 kg
  > Carton Meas: 310mm*275mm*290mm > Giftbox size: 119mm*113mm*26mm
